d&b KSL Steps Up for Chvrches

Scottish synth-pop trio Chvrches went on a stepped-up UK tour in support of their latest album,
Love is Dead. Glasgow-based concert audio supplier, FE Live, designed a d&b audiotechnik KSL
System to deliver the group’s journey through pop, indie and EDM to audiences in venues of varying

“Having used the d&b GSL System for the first time in America last year, I was excited to specify the
new KSL System for our UK shows,” said Chvrches’ FOH Engineer, Paul ‘Gal’ Gallagher.

“I’ve been a huge fan of the J-Series over the years and despite how good that is, I was blown away with the massive headroom and clarity in tricky rooms this new system offers – it’s a huge leap forward.”

Gallagher says that the key to sonic success with Chvrches is separation and clarity. “The challenge is
to keep the sound punchy and loud with the combination of electronic and vocal mix … The KSL System has so much power it’s almost frightening, making the vocal gain quite exceptional. The clarity and directivity is on an altogether higher level.”

FE Live’s MD, Ryan McIlravey, is touring with the band as system tech. He designed a KSL touring package of KSL8 and KSL12 cabinets, which could be simply scaled up for larger venue dates. The main touring package consisted of 20 x KSL8, 4 x KSL12 and 12 x SL-SUB; this was boosted with extra KSL8 and KSL12 cabinets for performances at London’s Alexandra Palace and the hometown gig at the SSE Hydro arena in Glasgow.

McIlravey continued: “KSL makes this easily achievable with features such as its increased vertical
splay angle (ten degrees v seven degrees with J-Series) which makes it more ‘box count efficient’ in
smaller rooms with limited trim heights. Compression rigging also aids in rapid system deployment
from a minimal footprint – great when floor space is limited.”

Chvrches Production Manager, Patrick Reid, said: “I was a bit apprehensive prior to this run about how we would scale the system to suit the different venues all with the same size box. After the first few shows it became clear this was not an issue in fact we could have even scaled up or down even further.”

The team utilised the d&b range of optimisation tools for the tour, including ArrayCalc, ArrayProcessing and the R1 remote control software.

“95% of the system tuning was done in ArrayCalc,” said FE Live’s Kevin McAtear. “You hardly need a measurement mic anymore if you put the time into accurate venue measurements. ArrayCalc isn’t affected by the ongoing noise from hard working crews, pyro tests, plant and machinery involved with getting today’s large shows ready for doors opening.”

“FE Live trusts ArrayCalc and invaluable d&b tools like ArrayProcessing to optimise the system as it saves time, creates less noise and produces great and easily repeatable results.”

FE Live also utilised an all ‘Dante’ drive system for the tour, with a d&b DS10 network bridge in every
amplifier rack, fed from a fibre enabled backbone with primary and secondary switch racks located at FOH, Stage Left and Stage Right. This network also carried OCA data for d&b R1 remote amplifier monitoring and control.

McIlravey concluded: “The KSL System represents the next generation in line array technology – it offers me so much control.” The UK dates were part of Chvrches world tour, which now travels to Australia, the US, Japan and Europe.

Photos Credit: Cameron Brisbane
